设备名称：智能激光履带封边机
设备型号：LASER930
品牌：诚诺机械
产地：广东东莞
封边方向
 分离
Separating agent  预铣
Pre-milling  烤灯
Hot lamp  上胶炉
Glue pot  PUR双色免清洗胶炉
PUR dual color no cleaning  压贴
Pressing  激光系统
Laser system 偏摆压贴
Pressing  双轨齐头齐尾
Double track, head and tail aligned  粗修
Rough trimming  精修
Fine trimming  四头跟踪
Four head tracking device  刮边①
Scraping 刮边②
Scraping  柔性平刮
Flexible flat scraping  抛光①
Polishing 抛光②
Polishing
主要技术参数
| 型号Model：LASER930 |
| 电动升降Electric lift |
电动式 |
进给速度Feed rate |
16-26m/min |
| 板材宽度Sheet width |
≥60mm |
输入电压Input voltage |
380V |
| 板材厚度Sheet thickness |
9-60mm |
空气气压Air pressure |
0.7mpa |
| 封带厚度Sealing thickness |
0.4-3mm |
总功率Gross power |
28KW |
| 封带宽度Sealing width |
12-65mm |
机器尺寸(长*宽*高)
Machine size (L * W * H) |
10670*950*1840mm |
|
